potentiometer rotary switch
WDD35D4 1K 2K 5K 回転ポテンチオメーター 精密伝導性プラスチックポテンチオメーター
Precision conductive plastic potentiometer WDD35D4 1K 2K 5K 10 K linear 0.1% product name: Precision conductive plastic potentiometer WDD35D4 1K 2K 5K 10 K linear 0.1% 0.5% angular displacement sensor product description: The WDD35 series products are made of hard aluminum alloy material as the outer shell, conductive plastic as the resistance material, and undergo molding and laser trimming fine adjustment. The precious metal brush surge device, stainless steel high-speed
WX110 ((010) 1W シングルターン傷口ポテンチオメーター 高精度 調整可能なノブ抵抗 470 オーム 1K 10K 22K
Product Description Specification item value Model Number WX110(010) Type Rotary Potentiometer Place of Origin China Brand Name BONENS Technology Wirewound Resistance 100 ohm~22K Resistance Tolerance ±5% Rated Power 1W Operating Temperature -55°C~ 125°C Tolerance ±5% Diameter 29mm Built in Switch None Rotation 300° Resistive Material Wirewound Termination Style Solder Lug Actuator Type Slotted Bushing Thread M10 x 1 Shaft Size 0.236" (6.00mm) Number of Turns 1 Company Profile
10kポテンチオメーター LA42DWQ-22 10kオム変速駆動ポテンチオメーター 22mm
10k Potentiometer LA42DWQ-22 10k ohm Variable Speed Drive Potentiometer 22 mm product name: 10k Potentiometer LA42DWQ-22 10k ohm Variable Speed Drive Potentiometer 22 mm product description: LA42DWQ-22 precision frequency converter speed regulation potentiometer, hole size: 22mm, resistance specification: 1K 2K 5K 10K resistor can be customized, potentiometer color: black, protection level: IP65, number of packaging, 10 pieces/box, LA42DWQ-22 precision frequency converter
AG2 プラスチックポテンチオメーターノブ 15X17MM WH148 ノブ 直径 6mm キャップ
AG2 plastic potentiometer knob 15X17MM plum blossom handle WH148 knob diameter 6mm cap product name: AG2 plastic potentiometer knob 15X17MM plum blossom handle WH148 knob diameter 6mm cap product description: Diameter: 15MM Height: 17mm Aperture: 6MM Available colors: red, blue, yellow, orange, white Suitable for sealing single (double) potentiometer, long (short) handle single (double) potentiometer rotary encoder with round handle. Product Features: Good material quality,
ボネンス wxd3590 10回転 5k 10k 20k 50k 100k 春回帰ポテンチオメーター
Bonens Wxd 3590 10 Turns 5k 10k 20k 50k100K Spring Return Potentiometer Product Description Specification Electrical Characteristics Range of nominal resistance 100~100KΩ Resistance tolerance ±2%, ±5% Terminal resistance ≤2%R or 5Ω Linear accuracy ±1%, ±0.5% Electrical angle 3600°±10° Insulation resistance ≥ 200MΩ Withstand voltage 500V (DC or AC peak value) Environment Characteristics Rated power 2W (70°C) Temperature range -55°C~+125°C TCR ±100×10-6/°C Temperature shock ΔR≤
100mm 移動線形 10K 30K スライドポテンチオメーター
product name: 100mm travel Linear 10K 30K slide potentiometer Specification ELECTRICAL CHARACTERISTICS Total Resistance 10K Ω±20% Resistance Taper A, B,C,D,E,MN,RD, W, Max. Operation Voltage Linear Taper B :AC 200 V~DC / V Other Tapers :AC 150 V~DC / V Rated Power Single unit: Linear taper B:0.2W, Other tapers : 0.05W Dual unit: Linear taper B:0.1W, Other tapers :0.025W Sliding Noise Less than 100 mV Insulation Resistance More than 100 MΩ at DC 250 V Withstand Voltage 1
1000W B100K B500K B470K WH116AKシリーズライトディマー用の線形回転電位計
product name WH116AK R16P2S Vertical Terminal Pcb Mount Dimmer Light Rotary Potentiometer WIth 10A High Current Push Press Switch lectrical Properties Operating Temperature Range: Wide range, e.g., (-20℃) to (100℃), ensuring operation under various environmental conditions. Switch Rating: AC 250V 10A, capable of handling high load currents and voltages. Switch Contact Resistance: Less than 50mΩ, ensuring good switch contact and reduced energy loss. Rated Power: 0.2W, suitable
WH116AKシリーズ 10A 高電流 プラスチックシャフト 長寿命 回転ポテンチオメーター 防塵ポテンチオメーター ディマー用
product name WH116AK-4R-1 light dimmer big current 1000W B100K B500K B470K dimmer linear b500k pcb mount linear rotary potentiometer product description WH116AK is a high-performance carbon film rotary potentiometer with a press switch function, widely used for dimming, speed regulation, and volume adjustment. Resistance value range: 1k Ω~2M Ω, allowable deviation of resistance value ± 18%, rated power: 0.2W, mechanical life: 50000 times. The main structure of WH116AK
WH116AK 電子機器用のプッシュスイッチ付きの炭素フィルム回転ポテンチオメーター
product name R16R2S 16mm B10K B20K B47K B470 B500K dimming speed control potentiometer product description WH116AK is a high-performance carbon film rotary potentiometer with a press switch function, widely used for dimming, speed regulation, and volume adjustment. Resistance value range: 1k Ω~2M Ω, allowable deviation of resistance value ± 18%, rated power: 0.2W, mechanical life: 50000 times. The main structure of WH116AK potentiometer is made of flame-retardant fiberglass
